3M™ Overhead Projector 1700 Series Illustrated Parts Breakdown
© 3M 2005. All Rights Reserved. 2
Quick Reference Parts Index
Description Part
Number
Section
No.
Item
No.
Blade, Fan 78-8054-1823-9 12 1
Diode Kit, Inline 78-8054-1836-1 12 8A
Fresnel Lens, Dual-Element XO-0038-0820-1 7 3
Fuse, 5 Amp, 5x20mm (Brazil only) 26-1005-9599-5 12 3
Singlet Head Assembly (1720, 1760, 1765 Gray color) 78-8120-8554-2 1 8A
Doublet Head Assembly (1730, 1780 Gray color) 78-8120-8555-9 1 8B
Open Head Assembly (1711, 1740, 1745 Gray color) 78-8120-8556-7 1 9
Lamp, Projection, ENX, 82V (Single) 78-8011-1186-1 10 3
Lamp, Projection, ENX, 82V (Dual) 78-8011-1186-1 11 4A
Lamp, Projection, FXL, 82V (1745 and 1765) 78-8073-7100-6 11 4B
Motor, Fan, 120V 78-8120-2914-4 12 7
Power Cord, 10 ft., 120V 78-8079-8822-1 8 4A
Resistor, 1.2 Ohm, 0.25 tab 78-8073-7127-9 9, 10 5A, 13
Socket, Single Lamp, ENX 78-8079-8820-5 10 2
Socket, Dual Lamp, Black 78-8073-3017-6 11 3
Thermostat, Safety (ENX) 78-8079-8872-6 10 7
Top Cover Assembly, Single (Beige color) 78-8114-9027-1 6 1A
Top Cover Assembly, Dual (Beige color) 78-8114-9021-4 6 1B
Top Cover Assembly, Basic (Gray color) 78-8120-8572-4 7 1A
Top Cover Assembly, Lamp Changer (Gray color) 78-8120-8573-2 7 1B
IMPORTANT NOTICE
3M reserves the right to sell or furnish NEW OR RECONDITIONED PARTS.
New and reconditioned parts are covered by the same 3M new parts limited warranty.
