3M™ Overhead Projector 1700 Series Illustrated Parts Breakdown
© 3M 2005. All Rights Reserved. 17
Base Enclosure Parts List
Item
No.
3M
Part Number
Description Qty.
1 78-8079-9141-5 Body Mirror Assembly 1
2A (Not available) Base, Fixed Post (Beige color) 1
2B (Not available) Base, Fixed Post (Gray color) 1
2C (Not available) Base, Folding Post 1
3 DY-1160-2020-6 Strain Relief 1
4A 78-8079-8822-1 Power Cord, 10 ft., 120V 1
4B (Not available) Power Cord, 2 Blade with ground, 127V (Brazil) 1
5 26-1008-5211-5 Foot, Mounting 4
6 78-8073-3039-0 Switch, Interlock Switch 1
7 (Not available) Cover, Interlock Switch 1
8 78-8079-8817-1 Pivot, Cover 2
9 (Not available) Clip/Clamp, 0.310 max bundle dia. 1
