3M™ Overhead Projector 1700 Series Illustrated Parts Breakdown
© 3M 2005. All Rights Reserved. 19
Control Module Parts List
Item
No.
3M
Part Number
Description Qty.
1 78-8073-2962-4 Knob, Lamp Changer 1
2A 78-8073-2963-2 Housing, Lamp Changer (1 Hole) 1
2B (Not available) Housing, Lamp Changer 1
3 78-8073-2961-6 Bracket, Lamp Changer 1
4A 78-8073-3012-7 Cover, Resistor, 20W 1
4B (Not available) Bracket, Resistor, 40W 1
5A 78-8073-7127-9 Resistor, 1.2 Ohm, 0.25 tab 1
5B (Not available) Resistor, 2.2 Ohm, 0.25 tab 1
6 12-7995-0850-7 Spring, Extension 1
7 78-8079-8881-7 Lever, Lamp Changer 1
8 78-8079-8933-6 Thermostat 1
9 78-8079-8855-1 Switch, Lamp Changer/Dimmer 2
10 78-8114-9017-2 Control Module (entire assembly) 1
