3M™ Overhead Projector 1700 Series Illustrated Parts Breakdown

Lamp Housing (Dual) Parts List

Item

No.

Part Number

Description Qty.

1 78-8079-8887-4 Rod, Lamp Changer 1

2 78-8079-8984-9 Sleeve, Insulator 1

3 78-8073-3017-6 Socket, Dual Lamp, Black 1

4A 78-8011-1186-1 Lamp, Projection, ENX, 82V 1

4B 78-8073-7100-6 Lamp, Projection, FXL, 82V (1745 and 1765) 1

5 78-8079-8863-5 Retainer, Lamp 2

6 (Not available) Plate, Dual Lamp, ENX 1

7 78-8079-8862-7 Ejector, Lamp 1

8 (Not available) Pivot, Dual Lamp Mount, ENX 1

9 (Not Available) Bracket, Lamp Mount, ENX 1

10 26-1009-7186-5 Clip, Shaft, Color Tuning 1

11 26-1009-7485-1 Spring, Compression 1

12 78-8079-8912-0 Knob, Color Tuning 1

13 78-8120-2913-6 Bracket, Motor 1

14A 78-8114-9019-8 Housing, Lamp (Beige color) 1

14B 78-8120-8458-6 Housing, Lamp (Gray color) 1

15 (Not available) Tape, Reflective, #7323, 3” x 60 yards 1

16 78-8079-8893-2 Shaft, Color Tuning 1

17 (Not Available) Clip/Clamp, Cable 2

18 (Not Available) Sleeve, Color Tuning 1

19 78-8079-8858-5 Plate, Dual Socket, ENX 1

20 78-8079-8923-7 Bracket, Wire Cover 1

21 78-8114-9020-6 Dual Lamp Assembly (Items 1,2,3,5,6,7,8,18,20)
