3M™ Overhead Projector 1700 Series Illustrated Parts Breakdown
© 3M 2005. All Rights Reserved. 5
Head Assembly Parts List
Item
No.
3M
Part Number
Description Qty.
1 78-8114-8795-4 Lens, Doublet Element 2
2A 78-8120-2934-2 Head Halves, Singlet (Beige color) 1
2B 78-8120-2935-9 Head Halves, Doublet (Beige color) 1
2C 78-8120-8451-1 Head Halves, Singlet (Gray color) 1
2D 78-8120-8464-4 Head Halves, Doublet (Gray color) 1
3 78-8014-8951-5 Lens, Wide Angle, 293mm (Singlet Head only) 1
4 78-8114-8812-7 Mirror 1
5 78-8120-3192-6 Label, Head 1
6 78-8120-2927-6 Lens, Head 1
7 78-8120-3072-0 Bracket, Head Mount, Closed Singlet (Gray color only) 1
8A 78-8120-8554-2 Singlet Head Assembly (1720, 1760, 1765 Gray color) 1
8B 78-8120-8555-9 Doublet Head Assembly (1730, 1780 Gray color) 1
9 78-8120-8556-7 Open Head Assembly (1711, 1740, 1745 Gray color) 1
10 78-8120-8501-3 Open Singlet Mirror Assembly 1
11 (Not available) Housing, Lens, Split, Open Singlet 1
To Next Page
