3M Dynatel 965AMS - Results Screen

125
3M™ Dynatel™ Advanced Modular System 965AMS Measurement Functions
POTS>Loss>Operation
e. Press
Dial
to begin
the test.
4. Point to Point
Measurements
1. Use a 965AMS tester
or a 965DSP tester set
to the tone mode.
2. Verify that both ends
of the circuit are on the
same frequency.
3. Press Send Tone at the
sending end.
4. Press
Measure
at the
receiving end.
5. Results screen:
POTS Loss Measurement Normal Range
