3M MP225 User Manual

3M
™
Mobile Projector MP225
10 © 2012 3M. All Rights Reserved.
English
Getting Started
Removing the Protective Film
When the projector is shipped, there is a protective film between the battery and
the battery contacts on the projector. Remove the protective film by removing the
battery and the protective film, discard the film and finally install the battery.
Install Battery
The 3M Mobile Projector MP225 comes with a rechargeable battery. The battery
should be fully charged before using the projector with the battery.
To install the battery: point the contacts on the battery toward the contacts on the
projector, insert the end farthest from the battery latch first, then push down until
the battery clicks into place.
Remove Battery
To remove the battery: slide the battery latch away from the battery and then lift the
battery out, starting at the end closest to the latch.
Important Note: Use only the 3M specified battery: 78-6972-0058-8.

3M MP225 Specifications

General

Projection distance	- m
Projection technology	-
Screen size compatibility	10 - 80 \
Projector native resolution	SVGA (800x600)
Focal length range	- mm
Light source type	LED
Service life of light source	20.000 h
Full HD	No
Supported graphics resolutions	832 x 624, 1280 x 960, 1024 x 768 (XGA), 1280 x 768 (WXGA), 1440 x 900 (WXGA+), 640 x 480 (VGA), 800 x 600 (SVGA)
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Internal storage capacity	2 GB
Noise level	- dB
Product type	Portable projector
Product color	White
Market positioning	Portable
Power source	Battery
Battery life (max)	2 h
Power consumption (standby)	- W

Weight and Dimensions

Depth	12 mm
Width	26 mm
Height	59 mm
Weight	300 g
