14
Component Dimensions Weight Electrical
Appliance
coupler
3.25 in. × 3.0 in. × 32.25 in. (max.)
8.26 cm × 7.62 cm × 81.9 cm
1.24 lb
0.56 kg
100–240 VAC, 12.0 A
V-Series Tabletop Unit specifications
System physical characteristics
Height
31.0 inches (78.7 cm)
Width
36.0 inches (91.4 cm)
Depth
30.5 inches (77.5 cm)
Weight
Laminate top
Corian® top
200 pounds (90.7 kg)
220 lbs. (99.8 kg)
Shipping weight
Laminate top
Corian® top
250 lbs. (113 kg)
270 lbs. (122 kg)
System operating environment
Humidity
0% to 85% RH, non-condensing
Operating temperature
50° F to 93° F (10° C to 34° C)
Storage temperature
−22° F to 131° F (−30° C to 55° C)
System power requirements
Voltage
100–120 VAC or 200–240 VAC
Current
6.0 A or 3.0 A
Frequency
50/60 Hz
Phase
Single
Power
600 Watts
Component specifications
Component Dimensions Weight Electrical
Touch screen
16.1 in. × 10.2 in. × 15.7 in.
40.9 cm × 25.9 cm × 39.9 cm
16.3 lb
7.4 kg
12 VDC, 2.0 A
Scanner
2.59 in. × 1.38 in. × 3.47 in.
6.58 cm × 3.51 cm × 8.81 cm
7.5 oz
213 g
24 VDC, 300 mA
Printer
6.25 in. × 8.5 in. × 5.87 in.
15.9 cm × 21.6 cm × 14.9 cm
4.2 lb
1.9 kg
24 VDC, 3.0 A
Interconnect
box
12 in. × 12 in. × 3 in.
30.5 cm × 30.5 cm × 7.62 cm
3.6 lb
1.6 kg
100–240 VAC, 1.0 A
Coil driver box
11.5 in. × 10 in. × 4.8 in.
29.2 cm × 25.4 cm × 12.2 cm
15.0 lb
6.8 kg
100–240 VAC, 1.0 A
V-cradle
6.6 in. × 16 in. × 18.4 in.
16.8 cm × 40.6 cm × 46.7 cm
5.0 lb
2.3 kg
Powered by coil
driver box
Computer
xx.x in. × x.xx in. × xx.x in.
xx.x cm × xx.x cm × xx.x cm
xx.x lb
xx.x kg
120 VAC, 5 A or
240 VAC, 2.5 A
