R-Series
The SelfCheck System R-Series models
consist of the following components:
(1) Color touch screen monitor
(2) Magnetic card reader (optional)
(3) Barcode scanner (behind monitor)
(4) Smart card reader (optional)
(5) Receipt printer
(6) RFID pad
(7) Interconnect box (inside furniture)
(8) Appliance coupler (inside furniture)
(9) Computer with keyboard and mouse
(inside furniture)
8410_UG_02
2
5
3
6
9
7
8
4
1
3M™ SelfCheck™ System R-Series components
BCS Model 9410
The SelfCheck System BCS model
consists of the following components:
(1) Barcode scanner
(2) Color touch screen monitor
(3) Computer
(4) Keyboard and mouse
(5) Receipt printer
1
2
3
5
9410_UG_02
3M™ SelfCheck™ System BCS components
WARNING
To reduce the risk associated with fire due to modification or incorrect
installation of system components or the use of non-approved replacement
components:
Do not attempt to modify or repair—no user serviceable parts—contact 3M
Service for repair.
Use approved system components installed by 3M service personnel only.
Install system components into desk or enclosure according to instructions and
specifications given in the appropriate site planning guide.
