BK4936 microphone using random incidence corrector and windscreen (Figures/Tables “K”)
053-469 RevC
SoundPro models SE and DL Data Addendum
BK4936 microphone using random incidence corrector and
windscreen (Figures/Tables “K”)
Tolerance: IEC 61672 class 1
Directional frequency response using side toward speaker
Figure K.1- 0-30degree incidence angles
-10
-5
0
5
10
100 1000 10000 100000
Frequency Hz
Relative dB
