Fig. 19
M-976 Head, Neck, and Shoulder Cover (for use with M-100/M-200/M-300)
The head, neck, and shoulder cover can be used to help keep the headgear and the wearer clean. To install:
- Remove the black visor gasket by pulling straight out in small sections with the visor in the up (open)
position. Retain visor gasket.
- Insert headgear into head, neck, and shoulder cover such that the black gasket on the cover is
towards the visor of the headgear.
- Grasp the black gasket and align with the edge of the groove in the top of the visor. Starting on
one side press the gasket rmly into the groove in small sections. Both gasket ribs should be fully
inserted into the groove (Fig. 20).
- Pull air inlet in back of headgear completely through small hole in back of the cover.
NOTE: After using the head, neck, and shoulder cover ensure a visor gasket (M-921) is re-installed on
M-Series Headgear prior to use.
Fig. 20
M-972 Flame Resistant Headgear Cover
The headgear cover can be used to help keep dirt, debris, overspray, etc. off the headgear shell. The two
slits in the headgear cover are to accommodate the optional M-985 Earmuff Kit on the M-100, M-200
and M-300 headgear. If you are using the earmuff kit, follow the procedures in this section for installing
the headcover when using the M-985 kit.
To install the headgear cover on M-Series Headgear (when optional M-985 Earmuff Kit is not being used):
- Remove the black visor gasket by pulling straight out in small sections with the visor in the up (open)
position. Retain visor gasket.
- To install the headgear cover, grasp the black gasket and align with the edge of the groove in the
top of the visor. Starting on one side press the gasket rmly into the groove in small sections. Both
gasket ribs should be fully inserted into the groove (Fig. 20).
