3nStar RPT006 - Remove the Printer Engine

- 22 -
6
1
5
6.1.4 Remove the printer engine
Remove the key label.
Remove the two PA3*8mm screws fixing
the lamp board with a cross screwdriver
and then remove the lamp board.
Explanatory chart
Diagram
A. Remove the cover button according to
the direction.
B. Remove the four TA3*10mm screws
fixing the engine with a cross screwdriver,
and then remove the engine.
