Transmission: 1200m
Interface protection: 1500W surge protection,15KV ESD protection
Baud rate: 300bps to 230400bps
Parity: None, Even, Odd, Space, Mark
Data bits: 7, 8
Stop bits: 1, 2
Flow Control: RTS/CTS, XON/XOFF
FIFO: 128bytes
Driver Support
Operating System: Support Windows98/ME and Windows2000/XP,Windows Server
2003/2008, Windows 7/Vista
Power
Power input: 5VDC power input
Consumption: 300mA
Environment
Operating temperature: -10°C to 60°C
Storage temperature: -40°C to 85°C
Humidity: 5% to 95%(no condensation)
Appearance
Dimensions: 160.0mm×94.0mm×28.0mm
Material: Iron(shell)
Color: White
Weight: 500g
Warranty: 3 years
Approvals: FCC, CE, RoHS approvals
5. Panel Layout
5.1 Front Panel
USB：USB connector
RX1, TX1, RX2, TX2, RX3, TX3, RX4, TX4: COM1 ～ 4 port receive and send
indicator
PWR: power indicator
5.2 Front Panel
COM1～4：RS-485/422port
