3Svision N9071 - Shortcut Bar

N9071 Mini Dome Network Camera 2 Megapixel + H.264
- 36 -
Shortcut Bar
Enable/Disable the application function from Shortcut Bar.
Microphone
Click the thumbnail of the Microphone on the shortcut bar to enable/disable it (one-way
audio).
 Transmit the voice into the N9071 Mini Dome Network Camera by using the PC’s
microphone.
Buzzer
Click the thumbnail of the Buzzer on the shortcut bar to enable/disable it (one-way audio).
 It can receive the voice of the microphone from the N9071 Mini Dome Network Camera.
Record
Microphon
e
Snapshoot
Path
Shortcut Bar Message
Buzzer
