N9071 Mini Dome Network Camera 2 Megapixel + H.264
- 9 -
Making Connections
Before you connect your N9071, please make sure your PC has the LAN port available for
connect to the network.
Follow these instructions to connect the N9071 into your PC and LAN Port.
Power Connect to DC12V power.
LAN Connect to 10/100 RJ45 network.
Power
Please connect N9071 Mini Dome Network Camera to the power supply from the DC/POE
Power Inlet. The power inlet of N9071 Mini Dome Network Camera is non-polarized, it can
automatically determine the type of the incoming current.
NOTE：
N9071 provide 2 different kind of power input including DC & POE.
Please make sure the accurate model to come with the purchasing.
Attention: Please take notice of connection of positive and negative electrode. Wrong connection will
damage the camera.
