4ms Sampler - Recording and File Management; Recording Channel and File Organization; Electrical and Mechanical Specifications

Recording channel:
• Stereo recording can be simultaneous to operation of playback channels"
•
Easily record output of sample playback, “bouncing” a play session into a new sample file"
• Recording initiated by button or trigger"
• Record into any sample slot in any bank"
•
Every recording is saved as a WAV file on the microSD Card"
• Recording can be disarmed to prevent accidental recordings"
• 48kHz/16-bit or 48kHz/24-bit stereo recording. Future firmware versions will support 96kHz"
• “Unlimited” recording time (records continuously until card is full)"
•
256GB card = 16+ days of continuous recording (~400 hours)"
•
Long recordings are split into 4GB WAV files"
File Organization:
• Includes a high-speed 16GB microSD card, loaded with over 200 samples"
•
Record new samples directly to banks with the Record input jacks"
• Load WAV files using a computer and the intuitive bank/color organization system"
•
Drag folders of WAV files onto the microSD card, and each folder will become a bank"
•
No need to rename WAV files"
•
Folders starting with a color name will be loaded into that color bank"
•
Example "Blue - Frooty Loops" will load into the Blue bank"
•
Sub-folders are ignored, only folders in the root directory are scanned for WAV files"
• Works best with “UHS Speed Class 3” cards with this symbol printed on the card: "
Electrical and Mechanical Specifications
• 16HP Eurorack format module"
• 0.98” (25mm) maximum depth"
• 10-pin Eurorack power header"
• Power consumption (maximums):"
•
+12V@145mA; -12V@39mA; +5V rail not used"
•
Audio Out jacks"
•
Out : File = -0.1dB max deviation from 20Hz - 10kHz; -3dB @ 20kHz"
•
21V peak-to-peak = full scale"
•
Audio RECORD jacks"
•
File : In = max -0.1dB 20Hz-6kHz, -0.9dB @ 6kHz - 20kHz"
•
Out : In = max -0.1dB 20Hz-10kHz, -0.7dB @ 15kHz, -3dB @ 20kHz"
•
21V peak-to-peak maximum before clipping"
•
Noise (unpatched In jacks): -84.3dB"
•
End Out jack"
•
+8V trigger pulse"
•
Pitch CV jack"
•
-5V to +5V range, for -5 to +5 octave shift"
•
Note: the Pitch jack combines with Pitch knob and sample file’s sample rate, and the
resulting pitch shift is limited to -9 octaves down and +4 octaves up"
•
CV jacks (Start Pos CV, Sample CV, Length CV, Bank CV)"
•
0 to +5V range"
•
Reverse, Play , Rec jacks"
•
Trigger voltage must be > 1.6V, rising edge is detected"
• microSD card slot accessible from front panel$
