Description of symbols
The rating plate on your tool may show symbols.
These represent important information about the
product or instructions on its use.
Wear hearing protection.
Wear eye protection.
Wear breathing protection.
Double insulated for additional protection.
For safe operation read instruction manual.
Conforms to UL STD 987
Certified to CAN/CSA STD No. 71.2-08
Specifications
Input power: 15 Amp
No load speed: 5500 RPM
Voltage: 120V ~ 60 Hz
Blade size: Ø 10” (254 mm) x Ø 5/8” (16 mm) bore
Number of teeth: 40
Miter table angles: 0° to 52° left & right
Bevel cuts: 0° to 45° left
Straight cut
0° x 0°: 3 1/4” (81.5 mm) x 11 5/8” (295 mm)
Miter cut
45° (L&R) x 0°: 3 1/4” (81.5 mm) x 8 1/16” (205 mm)
Bevel cut
0° x 45°(L): 1 5/8” (43 mm) x 11 5/8” (295 mm)
Compound miter cut
45°(L) x 45°(L): 1 5/8” (43 mm) x 8 1/16” (205 mm)
Weight: 29.7 lbs (13.5 kg)
