Basic description of the Transformer Monitor
LEREF "Verzeichnis Ueberschrift" \* MERGEFORMAT Index
Fehler! Verwenden Sie die Registerkarte 'Start', um Verzeichnis Ueberschrift
dem Text zuzuweisen, der hier angezeigt werden soll.Inhaltsverz
The following equation can be derived in common logarithms from equation (1) with Θ
hN
=
98°C.
This relationship is shown in the below table:
Relative service life consumption
Example:
10 hours at 104°C and 14 hours at 86°C consume (10 h x 2) + (14 h x 0.25) = 23.5 hours dur-
ing an operation period of 24 hours.
Note that the service life consumption is negligible below 80°C.
When the load and ambient temperature are constant, the relative service life consumption
is calculated with the relationship V x t. 't' is the time under load and V is the relative ser-
vice life consumption from equation (1).
More commonly, when the operating conditions are not constant, the transformer's service
life consumption is calculated according to the following equation:
Number of a time interval
Total number of the same time intervals
