STEP 7
Carefully flip the base over on to its legs. Important: Two people are
required to move the bed base. Do not drag across the floor. Do not
rest frame on its side, excessive pressure may damage the legs.
installation guide
For customer support, visit www.ahbeard.com or call: 1300 654 000
STEP 8
Use the CLIP LOCK system to connect
mattress to the base.
Begin by removing both screws on platform
of base using Phillips head screw driver.
STEP 10
Attach female end of clip lock section to base.
Follow the bolting diagram to install the Clip Lock Strap. Repeat
step for other side.
Bolt
Metal Washer
Black Washer
Clip Lock Strap
Base
STEP 9
The male end of clip lock system is attached
to underside of mattress. Place mattress on
base and secure clip lock to base.
STEP 11
Plug the base into a power source.
A surge protector is strongly recommended.
STEP 12
If setting up a Divided Queen adjustable base, please see the
additional instructions that were provided for setup before
proceeding.
