1.3.1 Dimensions
Description
Unit
EES 30
EES 40
EES 52
A
Total height
mm
930
1110
1370
D
Diameter of the apparatus
mm
520
520
520
R
Height of drain tap
mm
110
110
110
S
Height of T&P plug
mm
730
970
1210
1
Connection cold water
-
3
/4 " - 14 NPT
3
/4 " - 14 NPT
3
/4 " - 14 NPT
2
Connection hot water
-
3
/4 " - 14 NPT
3
/4 " - 14 NPT
3
/4 " - 14 NPT
3
Connection T&P plug
-
3
/4 " - 14 NPT
3
/4 " - 14 NPT
3
/4 " - 14 NPT
4
Connection drain tap
-
3
/4 " - 14 NPT
3
/4 " - 14 NPT
3
/4 " - 14 NPT
Description
Unit
EES 66
EES 80
EES 120
A
Total height
mm
1530
1540
1620
D
Diameter of the apparatus
mm
560
610
710
R
Height of drain tap
mm
110
110
110
S
Height of T&P plug
mm
1360
1330
1385
1
Connection cold water
-
3
/4 " - 14 NPT
3
/4 " - 14 NPT
3
/4 " - 14 NPT
2
Connection hot water
-
3
/4 " - 14 NPT
3
/4 " - 14 NPT
3
/4 " - 14 NPT
3
Connection T&P plug
-
3
/4 " - 14 NPT
3
/4 " - 14 NPT
3
/4 " - 14 NPT
4
Connection drain tap
-
3
/4 " - 14 NPT
3
/4 " - 14 NPT
3
/4 " - 14 NPT

A.O. Smith EES 80 Specifications

General

Brand	A.O. Smith
Model	EES 80
Category	Water Heater
Language	English
