A.O. Smith T-D2-OS User Manual

T-D2-IN / T-D2-OS Service Manual
Ver. 1.00
64
CONFIDENTIAL
6. After gas pressure has been set, deactivate the T-D2-IN or T-D2-OS, remove the manometer tube, and
replace the port screw.
Computer board
Figure 3
MAX button
MIN button
Increase button
Decrease button
Figure 1
Manifold port
Figure 2
To Manometer
Tube
