T-D2-IN / T-D2-OS Service Manual
Ver. 1.00
73
CONFIDENTIAL
14. Parts list
Item # Part # Description Common parts for other models
001
EK402 Case assembly (IN) T-K4-IN
EKK41 Case assembly (OS) T-K3-OS, T-K4-OS
002
EK434 Front cover (IN)
EK435 Front cover (OS)
003 EK401 Air blockage plate T-KJr2-IN/OS, T-K4-IN/OS
004 EKJ09 Bracket
T-K3, T-K3-Pro, T-K3-SP/OS,T-KJr2-IN/OS,
T-K4-IN/OS
005 EKJ64 Junction box
T-K3, T-K3-Pro, T-K3-SP/OS, T-H2-DV/OS ,
T-KJr2-IN/OS, T-K4-IN/OS, T-M50, T-M32
006 EKJ66 Junction box inner plate
T-K3, T-K3-Pro, T-K3-SP/OS, T-H2-DV/OS
T-KJr2-IN/OS, T-K4-IN/OS
007 EKK5H Back guard panel T-K3, T-K3-Pro, T-K3-SP/OS, T-K4-IN/OS
050 EW000 Screw M4×12 (W/Washer) *
051 EW001 Screw M4×10 (w/washer) *
052 EW002 Screw M4×10 (Coated) *
053 EW003 Screw M4x10 *
054 EW004 Hex head screw M4×12 (W/Washer) *
055 EW005 Hex head screw M4x8 *
056 EX014 Screw M4x10 *
057 EW00B
Screw M3x6 SUS3
*
058 EW008 Screw M3x10 *
059 EW00H Pan screw M4x12 (W/Washer) *
060 EW024 Pan screw M4x10 FEZN *
061 EKK31
Tap tight screw M4x12 FEZN
*
062 EW006 Pan screw M4x10 *
063 EW00A Screw M3x6 *
064 EW009 Screw M4x6 *
065 EW00D Pan screw M4x8 *
066 EC00X
Nylon clamp
T-K3, T-K3-Pro, T-K3-SP/OS, T-H2-DV/OS,
T-KJr2-IN/OS, T-K4-IN/OS, T-M32
