A.O. Smith T-D2-OS User Manual

T-D2-IN / T-D2-OS Service Manual
Ver. 1.00
74
CONFIDENTIAL
Item # Part # Description Common parts for other models
067 EM167 Wire clamp 60
T-K3, T-K3-Pro, T-K3-SP/OS, T-H2-DV/OS,
T-KJr2-IN/OS, T-K4-IN/OS, T-M50, T-M32
101 EKH5W Burner assembly T-H2-DV/OS, T-K4-IN/OS
102
EKH6T Manifold with gas valve assembly LP T-H2-DV/OS, T-K4-IN/OS
EKK5K Manifold with gas valve assembly NA T-K4-IN/OS
103
EKK25
Fan motor (IN)
T-K3, T-K3-Pro, T-K3-SP, T-H2-DV/OS, T-K4-IN,
T-M50, T-M32
EKK54
Fan motor (Out) T-K3-OS, T-K4-OS
104 EKK0G Burner holder gasket
T-K3, T-K3-Pro, T-K3-SP/OS, T-H2-DV/OS,
T-K4-IN/OS, T-M50
105 EKK2X Burner gasket
T-K3, T-K3-Pro, T-K3-SP/OS, T-H2-DV/OS,
T-KJr2-IN/OS, T-K4-IN/OS
106 EKK2V Burner window
T-K3, T-K3-Pro, T-K3-SP/OS, T-H2-DV/OS,
T-KJr2-IN/OS, T-K4-IN/OS, T-M50, T-M32
107 EKK2W Rod holder gasket
T-H2-DV/OS, T-KJr2-IN/OS, T-K4-IN/OS, T-M50,
T-M32
108 EKK0E Flame rod
T-K3, T-K3-Pro, T-K3-SP/OS, T-H2-DV/OS,
T-K4-IN/OS, T-M50, T-M32
109 EKK0F Igniter rod
T-K3, T-K3-Pro, T-K3-SP/OS, T-H2-DV/OS,
T-K4-IN/OS, T-M50, T-M32
110 EKK32 Rod holder
T-K3, T-K3-Pro, T-K3-SP/OS, T-H2-DV/OS,
T-K4-IN/OS, T-M50, T-M32
111 EKN61 Rod cap
T-K3, T-K3-Pro, T-K3-SP/OS, T-H2-DV/OS,
T-KJr2-IN/OS, T-K4-IN/OS, T-M50, T-M32
112 EK412 Burner damper T-K4-IN/OS
113 EKK2Y Manifold gasket A
T-K3, T-K3-Pro, T-K3-SP/OS, T-H2-DV/OS,
T-KJr2-IN/OS, T-K4-IN/OS, T-M50
114 EKK2K Manifold gasket B
T-K3, T-K3-Pro, T-K3-SP/OS,T-H2-DV/OS,
T-KJr2-IN/OS, T-K4-IN/OS, T-M50
115 TU001 Fan damper T-K4-IN
116 EKK2D Pressure port
T-K3, T-K3-Pro, T-K3-SP, T-H2-DV/OS,
T-K4-IN/OS, T-M50, T-M32
