A.O. Smith T-D2-OS User Manual

T-D2-IN / T-D2-OS Service Manual
Ver. 1.00
76
CONFIDENTIAL
Item #
Part # Description Common parts for other models
410
EKK2E
Outlet drain plug
T-K3, T-K3-Pro, T-K3-SP/OS, T-KJr2-IN/OS,
T-K4-IN/OS, T-M50
411 EKK2T
Output thermistor
T-K3, T-K3-Pro, T-H2-DV/OS, T-M50, T-M32
412 EKN34 Hi-Limit switch
T-K3, T-K3-Pro, T-K3-SP/OS, T-H2-DV/OS, T-M50,
T-M32
413 EK333 Overheat-cut-off fuse
T-K3, T-K3-Pro, T-K3-SP/OS, T-KJr2-IN/OS,
T-K4-IN/OS, T-M50
414 EKK2R
Heater
T-K3, T-K3-Pro, T-K3-SP/OS, T-KJr2-IN/OS,
T-K4-IN/OS
415 EKK2P Inlet heater
T-K3, T-K3-Pro, T-K3-SP/OS, T-H2-DV/OS,
T-KJr2-IN/OS, T-K4-IN/OS, T-M32
450 EKK27
Pipe heater fixing plate
T-K3, T-K3-Pro, T-K3-SP/OS, T-H2-DV/OS,
T-KJr2-IN/OS, T-K4-IN/OS, T-M50, T-M32
451 EK031 Heater fixing plate 16
T-H2-DV/OS, T-KJr2-IN/OS, T-K4-IN/OS, T-M50,
T-M32
452 EKK26 Fuse fixing plate 18
T-K3, T-K3-Pro, T-K3-SP/OS, T-H2-DV/OS,
T-KJr2-IN/OS, T-K4-IN/OS, T-M50, T-M32
453 EK029 Fuse fixing plate 14
T-K3, T-K3-Pro, T-K3-SP/OS, T-KJr2-IN/OS,
T-K4-IN/OS
454 EZM04 O-ring P4 FKM
T-K3, T-K3-Pro, T-K3-SP/OS, T-H2-DV/OS,
T-KJr2-IN/OS, T-K4-IN/OS, T-M50, T-M32
455 EZM06 O-ring P6 FKM
T-K3, T-K3-Pro, T-K3-SP/OS, T-H2-DV/OS,
T-KJr2-IN/OS, T-K4-IN/OS, T-M50, T-M32
456 EZM14 O-ring P14 FKM
T-K3, T-K3-Pro, T-K3-SP/OS, T-H2-DV/OS,
T-KJr2-IN/OS, T-K4-IN/OS
457 EZM15 O-ring P15 FKM
T-K3, T-K3-Pro, T-K3-SP/OS, T-H2-DV/OS,
T-KJr2-IN/OS, T-K4-IN/OS, T-M50, T-M32
458 EZM16 O-ring P16 FKM
T-K3, T-K3-Pro, T-K3-SP/OS, T-H2-DV/OS,
T-KJr2-IN/OS, T-K4-IN/OS, T-M50, T-M32
459 EKH30 Fastener “4-11” T-K3, T-K3-Pro, T-H2-DV/OS, T-M50, T-M32
460 EKK24
Fastener “14-22”
T-K3, T-K3-Pro, T-K3-SP/OS, T-H2-DV/OS,
T-KJr2-IN/OS, T-K4-IN/OS
