CONNECTIONS INSTRUCTIONS
The device is not a self fed. Therefore it is supplied by the coin
mechanism connected to machine on which it works. The device
can be also fed by a testing supplier.
The PROGRAMMER has to be connected to the serial connector
which is placed in the back part of coin mechanism.
Once connected it displays by steps of 2 seconds the following
writtens
“COMESTERO GROUP”
“MINI PROGRAMMER”
“ V.1.3 dated 05/12/01 “
“ VALIDATOR –00 ”
“ RM5-3 ”
The 3
rd
line shows the software version of the programmer.
The last 2 writtens the configuration of the coin mechanism as well
as the model
The available configurations are:
"
VALIDATOR - 00"
"VENDING TOTALIZER - 10"
"IMPULSIVE TOTALIZER - 20"
"PROGRESSIVE TIME - 30"
"CREDIT STORAGE TOTALIZER WITH RELEASE UPON REQUEST –
"TIME CREDIT STORAGE TOTALIZER WITH RELEASE UPON REQUEST –
"TOTALIZER FOR PHOTOCOPING MACHINES - 70"
The models concerned by the programmer are:
RM4 – RM5-2 – RM5-3.
If the coinmech is not recognized it will show:
“WRONG VERSION”
After 2 seconds it will go on first option:
“READ COUNTER ”
The PROGRAMMER automatically indicates the menu functions
according to the version of coin mechanism to which the
programmer is connected.
(reference “MENU TABLE” – 2
nd
part of manual).
NOTE: inside the programmer there is a battery type 6LR61-
9V.When switching on the unit, if the battery is low, will be
displayed the message “Battery Low”.
Please proceed to the sostitution.
IMPORTANT: change the battery every 6 months also if NO
message is shown on the programmer.
