2-21
Chapter 2: Motherboard information
7. USB 2.0 connectors (10-1 pin USB89, USB1011)
TheseconnectorsareforUSB2.0ports.ConnecttheUSBmodulecable
toanyoftheseconnectors,theninstallthemoduletoaslotopeningatthe
backofthesystemchassis.TheseUSBconnectorscomplywithUSB2.0
specicationthatsupportsupto480Mbpsconnectionspeed.
EMB-B75A USB2.0 connectors
PIN 1
GND GND S_USB_PP9_R S_USB_PN9_R +5V
+5V
S_USB_PN8_R
S_USB_PP8_R
GND GND
USB89
PIN 1
GND GND S_USB_PP11_R S_USB_PN11_R +5V
+5V
S_USB_PN10_R
S_USB_PP10_R
GND GND
USB1011
CAUTION!Neverconnecta1394cabletotheUSBconnectors.Doingsowill
damagethemotherboard!
NOTE: TheUSBmodulecableispurchasedseparately.
