Aaeon GENE-6310 - Floppy Drive Connector (CN6); Front Panel Connector (CN7)

SubCompact Board GENE- 6310
Chapter 2 Quick Installation Guide
2
-
15
2.16 Floppy Drive Connector (CN6)
Pin
Signal Pin
Signal
1 GND 2 DENSITY SELECT0
3 GND 4 N.C.
5
GND
6 DENSITY SELECT1
7
GND
8 INDEX
9
GND
10 MOTOR A
11
GND
12 DRIVE SELECT B
13
GND
14 DRIVE SELELCT A
15
GND
16 MOTOR B
17
GND
18 DIRECTION
19
GND
20 STEP
21
GND
22 WRITE DATA
23
GND
24 WRITE GATE
25
GND
26 TRACK 0
27
GND
28 WRITE PROTECT
29
GND
30 READ DATA
31
GND
32 HEAD
33
GND
34 DIKS CHANGE
2.17 Front Panel Connector (CN7)
Pin
Signal Pin
Signal
1 HDD LED# 2 VCC
3 GND 4 PWR LED
5 ESMI# 6 GND
7 RESETIN 8 GND
