SubCompact Board GENE- 6310
Chapter 2 Quick Installation Guide
2
-
17
2.20 Serial Port/ COM 2 (CN9)
The GENE-6310 offers two serial ports, one RS-232 and one
RS-232/422/485. These ports allow you to connect them to serial
devices (mouse, printers, etc.)
Pin
Signal Pin
Signal
1 CM2-1 2 CM2-2
3 CM2-3 4 CM2-4
5 GND 6 SDSRB2X
7 SRTSB2X 8 SCTSB2X
9 SRIB2X 10 N.C.
2.21 Parallel Port Connector (CN10)
Pin
Signal Pin
Signal
1 STROBE 14 AFD
2 PTD0 15 ERROR
3 PTD1 16 INIT
4 PTD2 17 SLIN
5 PTD3 18 GND
6 PTD4 19 GND
7 PTD5 20 GND
8 PTD6 21 GND
9 PTD7 22 GND
10 ACK 23 GND
11 BUSY 24 GND
12 PE 25 GND
13 SELECT 26 N.C.
