2.26 Serial Port/ COM 1 (CN18)
The GENE-6310 offers two serial ports, one RS-232 and one
RS-232/422/485. These ports allow you to connect them to serial
devices (mouse, printers, etc.).
Pin
Signal
1 NDCD1 2 NRXD1
3 NTXD1 4 NDTR1
5 GND 6 NDSR1
7 NRTS1 8 NCTS1
9 NRI 1 10 N.C.
2.27 IrDA Connector (CN19)
The IrDA connector (CN19) can be configured to support wireless
infrared module. With this module and applications such as laplink or
Win 95/98 Direct Cable connection, user can transfer files to or
from laptops, notebooks, PDA and printers that also equip IrDA
function. This connector supports HPSIR (115.2Kbps, 2 meters),
and ASK-IR (56Kbps).
Install infrared module onto IrDA connector and enable infrared
function from BIOS setup; moreover, make sure to have correct
orientation when you plug onto IrDA connector (CN19).
Pin
