2.24 Power Connector (CN15)
In single board computer (non-passive backplane) applications, you
will need to connect the power to the GENE-6310 board using
CN15. This connector is fully compatible with the standard PC
power supply connector. Please check the following table for its pin
assignment.
Pin
Signal
1 Vcc
2 GND
3 GND
4 +12V
2.25 USB Connector (CN16, CN17)
The GENE-6310 has 4 USB (Universal Serial Bus) ports that provide
complete functions to plug play, hot attach, or detach for up to 127
external devices. The USB interfaces comply with USB specification
Rev. 1.1 and can be disabled in the system BIOS setup.
Pin
Signal Pin
Signal
1 D0VDD 2 GND
3 D0- 4 GND
5 D0+ 6 D1+
7 GND 8 D1-
9 GND 10 D1VDD
