Aaeon GENE-6310 - PME# Connector for PCM-3794(CN23)

SubCompact Board GENE- 6310
Chapter 2 Quick Installation Guide
2
-
23
19 ADDR1 44 +5V
20 ADDR0 45 DASP
21 DATA0 46 DIAG
22 DATA1 47 DATA8
23 DATA2 48 DATA9
24 N.C. 49 DATA10
25 GND 50 GND
2.31 PME# Connector for PCM-3794 (CN23)
This connector can show the power management events of
PCM-3794 (PC/104 + expansion interface, made by AAEON)
which is connected to GENE-6310 to provide the function of “Hot
Swap.”
Pin
Signal
1 N.C.
2 GND
3 PME#
4 SMBDATA
5 SMBCLK
