Half-size CPU Card HSB-668I
Chapter 2 Quick Installation Guide
2 - 7
CN5 TTL 18/24BIT Channel Connector
CN6 TTL 36BIT Channel Connector
CN7 LVDS Channel Connector
CN8 PS2 Keyboard/Mouse Connector
CN9 Internal Keyboard Connector
DOC 1 Disk on Chip Socket
To Next Page
