2.24 LVDS Channel Connector (CN7)
Pin Signal Pin Signal
1
BKLEN
2
BKLCTL
3
PPVCC
4
GND
5
CH1_CLK#
6
CH1_CLK
7
PPVCC
8
GND
9
CH1_TX0#
10
CH1_TX0
11
CH1_TX1#
12
CH1_TX1
13
CH1_TX2#
14
CH1_TX2
15
CH1_TX3#
16
CH1_TX3
17
I2C_DATA
18
I2C_CLK
19
CH2_TX0#
20
CH2_TX0
21
CH2_TX1#
22
CH2_TX1
23
CH2_TX2#
24
CH2_TX2
25
CH2_TX3#
26
CH2_TX3
27
PPVCC
28
GND
29
CH2_CLK#
30
CH2_CLK
2.25 PS2 Keyboard/Mouse Connector (CN8)
Pin Signal
1 KB_DATA
2 MS-DATA
3 GND
4 +5V
