Aaeon HSB-668I - ATX Power Control Connector (CN2); LAN LED Connector (CN3;CN4); 18;24 Bit TTL Channel Connector (CN5)

Half-size CPU Card HSB-668I
Chapter 2 Quick Installation Guide
2 - 13
2.20 ATX Power Control Connector (CN2)
Pin Signal
1 PS-ON
2 +5V
3 +5VSB
AT Power Use: Close Pin 2,3
2.21 LAN LED Connector (CN3/CN4)
Pin Signal Pin Signal
1 Link_LED(-) 2 Active_LED(+)
2.22 18/24Bit TTL Channel Connector (CN5)
Pin Signal
Pin Signal
1 +5V 2 +5V
3 GND 4 GND
5 +3.3V 6 +3.3V
7 ENBKL 8 GND
9 BLUE0(24bit),NC(18bit) 10 BLUE1(24bit) ,NC(18bit)
11 BLUE2(24bit), BLUE0(18bit) 12 BLUE3(24bit), BLUE1(18bit)
13 BLUE4(24bit), BLUE2(18bit) 14 BLUE5(24bit), BLUE3(18bit)
15 BLUE6(24bit) ,BLUE4(18bit) 16 BLUE7(24bit), BLUE5(18bit)
17 GREEN0(24bit) ,NC(18bit) 18 GREEN1(24bit) ,NC(18bit)
19 GREEN2(24bit) ,GREEN0(18bit) 20 GREEN3(24bit), GREEN1(18bit)
21 GREEN4(24bit), GREEN2(18bit) 22 GREEN5(24bit) ,GREEN3(18bit)
