Aaeon HSB-668I - USB Connector (USB1); Fan Connector (FAN1); AC97 Connector (CN1)

Half-size CPU Card HSB-668I
Chapter 2 Quick Installation Guide 2-12
23 PE 24 GND
25 SELECT 26 N.C
2.17 USB Connector (USB1)
Pin Signal Pin Signal
1 +5V 2 GND
3 USBD1- 4 GND
5 USBD1+ 6 USBD2+
7 GND 8 USBD2-
9 GND 10 +5V
2.18 Fan Connector (FAN1)
Pin Signal
1 GND
2 +5V
3 Speed Sense
2.19 AC97 Connector (CN1)
Pin Signal Pin Signal
1
AC_RST-
2
AC_SYNC
3
AC_DAIN2
4
AC_DAOUT
5
GND
6
AC_BCLK
7
GND
8
+5V
9
Lock
10
+3.3V
