Aaeon HSB-668I - Irda Connector (IR1); LPT Port Connector (LPT1)

Half-size CPU Card HSB-668I
Chapter 2 Quick Installation Guide
2 - 11
5 GND 6 DSR
7 RTS 8 CTS
9 RIB / +5V 10 N.C
2.15 IrDA Connector (IR1)
Pin Signal
1 +5V
2 N.C
3 IRRX
4 GND
5 IRTX
6 N.C
2.16 LPT Port Connector (LPT1)
Pin Signal Pin Signal
1 #STROBE 2 #AFD
3 DATA0 4 #ERROR
5 DATA1 6 #INIT
7 DATA2 8 #SLIN
9 DATA3 10 GND
11 DATA4 12 GND
13 DATA5 14 GND
15 DATA6 16 GND
17 DATA7 18 GND
19 #ACK 20 GND
21 BUSY 22 GND
