Aaeon HSB-668I - 36 Bit TTL Channel Connector (CN6)

Half-size CPU Card HSB-668I
Chapter 2 Quick Installation Guide 2-14
23 GREEN6(24bit), GREEN4(18bit) 24 GREEN7(24bit), GREEN5(18bit)
25 RED0(24bit) ,NC(18bit) 26 RED1(24bit) ,NC(18bit)
27 RED2(24bit), RED0(18bit) 28 RED3(24bit) ,RED1(18bit)
29 RED4(24bit), RED2(18bit) 30 RED5(24bit), RED3(18bit)
31 RED6(24bit), RED4(18bit) 32 RED7(24bit), RED5(18bit)
33 GND 34 GND
35 DOT_CLOCK 36 VSYNC
37 DE 38 HSYNC
39 N.C 40 ENAVEE
2.23 36Bit TTL Channel Connector (CN6)
Pin Signal Pin Signal
1 GND 2 GND
3 SBLUE0(36bit) 4 SBLUE1(36bit)
5 SBLUE2(36bit) 6 SBLUE3(36bit)
7 SBLUE4(36bit 8 SBLUE5(36bit)
9 SGREEN0(36bit) 10 SGREEN1(36bit)
11 SGREEN2(36bit) 12 SGREEN3(36bit)
13 SGREEN4(36bit) 14 SGREEN5(36bit)
15 SRED0(36bit) 16 SRED1(36bit)
17 SRED2(36bit) 18 SRED3(36bit)
19 SRED4(36bit) 20 SRED5(36bit)
