40
APPENDIX I
AALBORG7 XFM EEPROM Variables Rev.A0 [12/19/2006]
Gas Independent Variables
INDEX NAME DATA TYPE NOTES
0
BlankEEPROM char[10] Do not modify. Table Revision [PROTECTED]
1
SerialNumber char[20] Serial Number [PROTECTED]
2
ModelNumber char[20] Model Number [PROTECTED]
3
SoftwareVer char[10] Firmware Version [PROTECTED]
4
TimeSinceCalHr float Time since last calibration in hours.
5
Options1 uint Misc. Options*
6
BackLight int Back Light Level [0-4095]
7
AddressRS485 char[4] Two character address for RS485 only
8
GasNumber int Current Gas Table Number [0-9]
9
FlowUnits int Current Units of Measure [0-22]
10
AlarmMode char Alarm Mode ['E’- Enabled, 'D’ - Disabled]
11
LowAlarmPFS float Low Flow Alarm Setting [%FS] 0-Disabled
12
HiAlarmPFS float High Flow Alarm Setting [%FS] 0-Disabled
13
AlmDelay uint Flow Alarm Action Delay [0-3600sec] 0-Disabled
14
RelaySetting char[4] Relays Assignment Setting (N, T, H, L, R, M)
15
TotalMode char Totalizer Mode ['E’- Enabled, 'D’ - Disabled]
16
Total float Totalizer Volume in %*s (updated every 6 min)
17
TotalFlowStart float Start Totalizer at flow [%FS] 0 - Disabled
18
TotalVolStop float Totalizer Action Limit Volume [%*s] 0-Disabled
19
KfactorMode char D-Disabled, I-Internal, U-User Defined
20
KfactorIndex int Internal K-Factor Index [0-35]**
21
UserDefKfactor float User Defined K-Factor
22
UDUnitKfactor float K-Factor for User Defined Units of Measure
23
UDUnitTimeBase int User Defined Unit Time Base [1, 60, 3600 sec]
24
UDUnitDensity char User Defined Unit Density Flag [Y, N]
25
AoutScaleV float DAC 0-5 Vdc Analog Output Scale
26
AoutOffsetV float DAC 0-5 Vdc Analog Output Offset
27
AoutScale_mA float DAC 4-20mA Analog Output Scale
28
AoutOffset_mA float DAC 4-20mA Analog Output Offset
29
SensorZero uint DPW value for Sensor Zero [0-1023]
30
Klag [0] float DRC Lag Constant [Do Not Alter]
31
Klag [1] float DRC Lag Constant [Do Not Alter]
32
Klag [2] float DRC Lag Constant [Do Not Alter]
33
Klag [3] float DRC Lag Constant [Do Not Alter]
34
Klag [4] float DRC Lag Constant [Do Not Alter]
To Next Page
