Aalborg XFM Series User Manual

42
Calibration Table: Gas Dependent Variables.
Note: Values will be available for selected gas only.
INDEX NAME DATA TYPE NOTES
100
GasIdentifer char[20] Name of Gas [If not calibrated = “Uncalibrated”]
101
FullScaleFlow float Full Scale Range in l/min
102
StdTemp float Standard Temperature
103
StdPressure float Standard Pressure
104
StdDensity float Gas Standard Density
105
CalibrationGas char[20]
Name of Gas used for Calibration
[If not calibrated=[“Uncalibrated”]
106
CalibratedBy char[20] Name of person who performed actual calibration
107
CalibratedAt char[20] Name of Calibration Facility
108
DateCalibrated char[12] Calibration Date
109
DateCalibrationDue char[12] Date Calibration Due
110
K_N
2
float Gas Parameters: K-factor relative to N
2
111
K_F1 float Reserved
112
K_F1 float Reserved
113
SensorTbl[0][Sensor Value] uint Index 0: Must be 120 (zero value) Do not Alter!
114
SensorTbl[0][Flow] float Index 0: Must be 0.0 (zero PFS) Do not Alter!
115
SensorTbl[1][Sensor Value] uint 10.0%F.S. A/D value from sensor [counts].
116
SensorTbl[1][Flow] float Actual Flow in PFS [0.1].
117
SensorTbl[2][Sensor Value] uint 20.0%F.S. A/D value from sensor [counts].
118
SensorTbl[2][Flow] float Actual Flow in PFS [0.2].
119
SensorTbl[3][Sensor Value] uint 30.0%F.S. A/D value from sensor [counts].
120
SensorTbl[3][Flow] float Actual Flow in PFS [0.3].
121
SensorTbl[4][Sensor Value] uint 40.0%F.S. A/D value from sensor [counts].
122
SensorTbl[4][Flow] float Actual Flow in PFS [0.4].
123
SensorTbl[5][Sensor Value] uint 50.0%F.S. A/D value from sensor [counts].
124
SensorTbl[5][Flow] float Actual Flow in PFS [0.5].
125
SensorTbl[6][Sensor Value] uint 60.0%F.S. A/D value from sensor [counts].
126
SensorTbl[6][Flow] float Actual Flow in PFS [0.6].
127
SensorTbl[7][Sensor Value] uint 70.0%F.S. A/D value from sensor [counts].
128
SensorTbl[7][Flow] float Actual Flow in PFS [0.7].
129
SensorTbl[8][Sensor Value] uint 80.0%F.S. A/D value from sensor [counts].
130
SensorTbl[8][Flow] float Actual Flow in PFS [0.8].
131
SensorTbl[9][Sensor Value] uint 90.0%F.S. A/D value from sensor [counts].
132
SensorTbl[9][Flow] float Actual Flow in PFS [0.9].
133
SensorTbl[10][Sensor Value] uint 100.0%F.S. A/D value from sensor [counts].
134
SensorTbl[10][Flow] float Flow in PFS. Should be 1.0 Do not Alter!
