73
*1: Width of the opening when a clear plate is removed
*2: Inside dimension
*3: Weighing pan diameter
*4: Height from the weighing pan up to the cap of the breeze break (Inside dimension)
*5: Height of the opening when a clear plate is removed
193
71.5
61.5
168.5
85.5
162
φ
150
262.5
194.5
184
171.5 (*2)
85.5 85 (*4)
82 83.5 (*5)
176
184
168.5
171.5
(*2)
262.5
193
115 (*1)
115 (*1)
φ
130
(*3)
162
71.5
61.5 194.5
FZ-120GD / 200GD / 300GD
FX-120GD / 200GD / 300GD
FZ-1200GD / 2000GD / 3000GD
FX-1200GD / 2000GD / 3000GD
* The FZ-1200GD / 2000GD / 3000GD
have a small break breeze provided.
Unit: mm
