Antenna Installation Guide
Manoeuvre the antenna base so that bottom of the base “catches” under the hole, the gold button
on top of the antenna base is facing up and the base is centred in the hole:
The O-ring gasket of the locking ring should seal to the mounting surface when threaded onto the
base:
