Aarcomm'Systems'Inc.' 18'Fawcett'Rd.,'Coquitlam,'B.C.,'V3K'6X9,'Canada' Page'4'
Telephone:''+1'(604)'265-8500' Email:''support@aarcomm.com' Rev.'3'
Antenna Installation Guide
Only if the mounting surface is less than 1.25 mm (0.05 inch) thick or if using the bracket, install the
supplied flat rubber washer as shown below (do NOT install the rubber washer if the mounting
surface is thicker than 1.25 mm):
The bottom end of the antenna whip should be slightly proud of the convex side of the bushing
under the base-cap of the whip. Use the supplied Allen key to adjust and/or tighten the set screw in
the bushing:
