Detail features
 2 000 users with card and PIN
 3 identification modes: card, PIN, card + PIN
 Read both 125KHz EM & HID card
 PIN length: 4-8 digits
 Pulse mode, Toggle mode of lock relay
 Wiegand 26-37 input & output
 Can be worked as controller or reader
 One relay output for door opening, inputs for door status detecting and open door by button
 Card block enrollment
 Manager cards for adding or deleting card user easily
 Very low power consumption (35mA)
 Backlight keypad
 Light and sound of keypad can be set on/off
 Support door bell connection
 Built in light dependent resistor (LDR) for anti tamper
 Built in buzzer
 Red, yellow and green LED display the working status
 12-24V DC
Operating Voltage 12~24V DC
User Capacity 2 000 with card and PIN (1234 - default PIN)
Keypad 12 keys, 3 x 4 digits and 2 x 6 digits (KZ-900)
Card Type EM & HID 125 KHz card, Mifare (13,56 MHz)
Card Reading Distance 3~6 cm (125 kHz), 2~5 cm (13,56 MHz),
Recommended supply power 2A (controller unit plus electric lock)
Idle Current ≤35mA
Lock Output Load Maximum 1A
Alarm Output Load Maximum 1A
Bell Output Load Maximum 1A
Operating Temperature -20~60℃
Operating Humidity 0%~95% (non condensing)
Environment Confirms to IP65
Adjustable Door Relay time 1~99 seconds, 3s - factory default
Adjustable Alarm Time 0~3 minutes, 1 min. - factory default
Wiegand Interface Wiegand 26~37 input & output
Wiring Connections Electric lock, External alarm, Door status (NC),
Exit button (NO), Bell
Dimensions:
KZC-800-U/H/M
KZC-900-U/H
125 x 83 x 22 mm (HxWxD)
159 x 43 x 22 mm (HxWxD)
