SPECIFICATIONS Page 2
SAFETY INSTRUCTIONS Page 3
REAR PANEL FUNCTIONS Page 4
FRONT PANEL FUNCTIONS Page 6
REMOTE FUNCTIONS Page 7
Contents:Specifications:
User’s guide
CAUTION: To reduce the risk of electric shock, do not remove cover (or back).
No user serviceable parts inside. Refer servicing to qualified service personnel.
WARNING: To reduce the risk of fire or electric shock, do not expose the preamplifier to rain or moisture.
The lightning flash with an arrowhead symbol within an equilateral triangle, is intended to alert
the user to the presence of uninsulated ‘dangerous voltage’ within the product’s enclosure that
may be of sucient magnitude to constitute a risk of electric shock to persons.
Output: Max 7.5Vrms unbalanced (RCA) or 15Vrms balanced (XLR)
Distortion, line stage: <0.003% (THD at 1kHz, 1Vrms input)
Output impedance: 50 ohms (unbalanced) or 100 ohms (balanced)
Phono: Floating RCA (1 set)
Load-impedance adjustable from 50 Ohm to 10 kOhm
Frequency response: +/-0.5dB (20Hz-20kHz)
Noise < -100dB at 2Vrms out
Distortion < 0.01% (20Hz-20kHz)
RIAA correction curve
Gain: 62dB
Line: Line 1: Gain: 14.5dB Input impedance: 5kOhm
Line 2: Gain: 9dB Input impedance: 10kOhm
Line 3: Gain: 5.5dB Input impedance: 10kOhm
Digital: 2 x RCA S/P-DIF (32-192kHz, 16-24 bit)
2 x TOSLINK optical (32-96 kHz, 16-24 bit)
1 x USB fully isolated, UAC 2, asynchronous (PCM 32-192kHz, 16-24 bit and DSD64/
DSD128)
Volume control: Volume adjustable from -80dB to 0dB in 80 1dB steps
Trigger outputs: Two outputs with 12VDC 100mA available on each.
Two 1/8” sockets, for stereo or mono jacks, with positive pole on the tip.
Dimensions: 100 x 440 x 370mm
Weight: 16.5 kg
▲
▲
▲
▲
▲ ▲
▲ ▲
▲
▲
▲
C-300 Preamplifier
