System Overview
The API 5000™ LC/MS/MS system includes a triple quadrupole mass
spectrometer, a Turbo V™ ion source, a computer, and the Analyst
®
software.
Figure 1-1 API 5000™ system and bench
Principles of the System
This section describes features and applications of the API 5000™ system.
Applications for the System
The API 5000 system is designed for quantitative analysis of small molecules.
This application involves measurement of specific molecular weight compounds,
usually a drug or metabolite in urine or other body fluid, and their resulting
WARNING! If you need to move the system, contact an FSE to assist you. Risk of
personal injury or instrument damage
Note: Before you operate the instrument, make sure you have read the Safety Practices
guide.
Bench
Mass Spectrometer
Line Adjustment
Transformers
Roughing Pumps
