ABB 2117 U-500 - Technical Data

DALI potentiometer for broadcast
operation
Technical data
| 1473-1-7978 — 8 —
Pos: 16 /#Neustruktur#/Modul-Struktur/Online-Dokumentation/Überschriften (--> Für alle Dokumente <--)/1. Ebene/S - T/Technische Daten @ 11\ mod_1279185386320_15.d ocx @ 83019 @ 1 @ 1
5 Technical data
Pos: 17 /#Neustruktur #/Modul-Struktur /Online-Dokumenta tion/Technische Dat en/Dimmer/Technisc he Daten - 2117 @ 21\mod_133120 3423023_15.doc x @ 201983 @ @ 1
2117 U-500
Nominal voltage:
(via an external DALI power supply)
9.5 – 22.5 V
"
Power consumption:
(dependent on the colour of the orientation illumination)
7 – 15 mA
Protective circuit electronic
Maximum connectable DALI operating devices:
(dependent on an external power supply)
64
Operating temperature: 0° C – +35° C
Protective class: IP20
Maximum cable length in the system: 300 m
Number of colours of the light for orientation: 18 + Off
2117/11 U-500
Nominal voltage: 230 V~ ±10%, 50 / 60 Hz
Power consumption: 7 – 15 mA
Open circuit voltage, output voltage: 15.5 V
"
Maximum drawn current: 75 mA
Protective circuit electronic
Maximum connectable DALI operating devices: 37
Operating temperature: 0° C – +35° C
Protective class: IP20
Maximum cable length in the system: 300 m
Number of colours of the light for orientation: 18 + Off
