CHAPTER 2 - Technical specification
MANIU04.9607 GB 03/97
Page 2.2
Table 2/2 contains, for each servomotor, values of axial and radial loads that must not be
exceeded to guarantee a regular lifetime of about 20000 hours in continuous duty of the
bearings with permanent lubrication. In general, a locked bearing is assembled on the motor
A-side.
Fig. 2-1
Table 2/2
Speed
[RPM]
Bearing type Radial load
F
R
[N]
Axial load
F
A
[N]
Servomotor
Type
SERIES 8
n
1
n
N
A-side
(shaft end)
B-side a n
1
a n
N
a n
1
a n
N
Dist.
z
[mm]
861
3000
6000
6004-2ZR-C3 6002-2ZR-C3 475 375 290 240 20
864
1500
3000
6205-2ZR-C3 6204-2ZR-C3 950 750 575 475 20
865
1500
3000
6207-2ZR-C3 6205-2ZR-C3 1750 1400 1000 850 2715
Notes:
(1) Values for simultaneous axial and radial stresses are available on request.
(2) Values for versions with integrated brake (special versions) are available on request.
(3) Values for admissible axial loads are valid for force direction F
A
towards the motor; for the opposite direction a
reduction is necessary (values available on request).
CAUTION: Taking into account the foreseen duration, the radial laads F
R
must not exceed
the values indicated, even for a transient period (acceleration, deceleration). In
particular, shocks provoked for example by the assembling of mechanical parts
(couplings, key nuts, etc ... ) on the shaft end are not allowed.
2.2 Specifications of digital convertors SERIES BHL-D
