CHAPTER 2 - Technical specification
MANIU04.9607 GB 03/97
Page 2.3
Table 2/3
BHL
-
D MODELS
5/10*
10/20*
14/28*
18/36*
25/50**
35/70**
50/100**
Power supply 220 Vac ±10% three-phase 50/60 Hz
Max output voltage 310 Vac three-phase
Rated current [Arms] 5 10 14 18 25 35 50
Peak current (max. 1.7s) [Arms] 10 20 28 36 50 70 100
Rated power to the motor [kVA] 1.8 3.6 5.0 6.5 9.0 12.7 18.2
Peak power to the motor (max. 1.7s) [kVA] 3.6 7.2 10.0 13.0 18.0 25.4 36.4
Peak power of ballast circuit 3900 3900 5700 5700 11400 11400 19000
(max. 0.5s) [W]
Standard continuous power of ballast circuit 90 90 180 180 370 370 740
( R
Bstandard
) [W]
Max. continuous power of ballast circuit 900 900 1500 1500 2700 2700 4000
(optional) (R
Bextra
) [W]
Switching frequency [kHz] 5 5 5 5 10 10 10
Speed range 0
÷
6000 RPM (f
max
= 300Hz)
Position transducer 2-pole resolver
Resolver-motor phase adjustment Automatic procedure
Speed reference input ±10V ( input impedance 200kΩ), differential
Current reference input ±10V (input impedance 24 kΩ)
Torque analog limit circuit input 0
÷
+10V(input impedance 24 kΩ)
Input for enabling commands Galvanically insulated
Reference supply outputs ±10V; 10 mA; stabilized
Output for enabling commands supply +15V; 100mA ( short-circuit protection)
Alarm relay: contact capability 0.5 A; 50 Vdc max; normally closed
Operating temperature 0
÷
40° C
Stock temperature
-25°
÷
+ 70° C
Humidity 90% max without dew
Altitude ≤1000 m above sea level
Protection degree IP 20
* Models availabie only in size 223 ** Models availabie only in size 224
2.3 Specifications of convertors and combinations servomotor/convertor
