CHAPTER 2 - Technical specification
MANIU04.9607 GB 03/97
Page 2.4
Table 2/4
PDS performances Servomotor
Type
SERIES 8
Convertor
Type
BHL-D 1310
T
0
[Nm]
T
max
[Nm]
T
Nmax
[Nm]
I
max
[Arms]
861.130 ...5/10... 1.3 3.9 3.9 6.0 
861.1.60 ...5/10... 1.3 3.9 3.9 9.3 
861.2.30 ...5/10... 2.5 7.5 7.4 9.0 
861.2.60 ...5/10... 2.35  4.7  4.7 10
861.3.30 ...5/10... 3.6 9.5  8.5 10
861.3.60 ...10/20... 3.6 9.5  9.4 20
864.0.15 ...5/10... 4.0 12 10.9 8.7 
864.0.30 ...5/10... 3.65  7.3  7.3 10
864.1.15 ...5/10... 6.5 18.1  12.8 10
864.1.30 ...10/20... 6.5 17.4  17.4 20
864.2.15 ...5/10... 9.1  18.2  18.2 10
864.2.30 ...10/20... 9.6  19.2  19.2 20
864.1.15 ...10/20... 12.0 34.2  34.2 20
864.3.30 ...14/28... 12.0 26.3  26.3 28
865.1.15 ...10/20... 15.0 36.2  36.2 20
865.1.30 ...14/28... 13.8  27.7  27.7 28
865.2.15 ...14/28... 21.0 48.2  48.2 28
865.230 ...18/36... 19.4  38.9  38.9 36
865.2.30 ...25/50... 21.0 54  40.2 50
865.3.15 ...14/28... 27.1  54  54 28
865.3.30 ...35/70... 29.0 67.9  67.9 70
865.4.15 ...18/36... 36.0  72  72 36
865.4.15 ...25/50... 37.0 100  100 50
865.4.30 ...35/70... 37.0 77.7  77.7 70
Legend
T
0
= Continuous stall torque
T
max
= Peak stall torque
T
Nmax
= Peak torque at nominal speed
I
max
= Motor current at T
max

The maximum current of the convertor (set through the parameter P5,I_MAX) must be limited to
this value.

The peak stall torque that can be obtained is limited by the value of the maximum current of the
convertor, which corresponds to P5,I_MAX = 200%.

The continuous stall torque of the PDS is limited by the value of nominal current of the convertor,
which corresponds to P5,I_MAX=100%.
WARNING !: In cases marked by note , if the value indicated for current is
exceeded, the motor is seriously damaged.
