Operation Manual / 4 Product description / A200-L

12 Spare parts / 12.1 Ordering spare parts

Customer spare part set (97071)

Customer spare part set is required for service work on the turbocharger after 18,000 hours.

Quantity Designation Part number

1 O-ring 77040

1 O-ring 79020

1 O-ring 79021

Table51: Customer spare part set (97071)

u Dispose of replaced parts and parts that are not reusable in a professional and environ-

mentally compatible manner.
